Naming regulation
1. A——Company name: It is represented by the company abbreviation “XMâ€.
2, B - lamp name: the first letter of the Chinese pinyin of the first two words "light bar" in the ceiling light, uppercase is "DT";
3, C - luminous color code: LED's luminous color mainly red (Red), yellow (Yellow), blue (Blue), green (Green), white (White), respectively, with "R", " Y", "B", "G", "W" are indicated.
4. D——Models using lamp beads: The LEDs currently used for soft strips are generally 3528 and 5050, which are represented by “35†and “50â€.
5. E——represents the number of lamp beads in each light bar: generally there are two kinds of 60PCS/M and 120PCS/M, which are represented by “06†and “12†respectively.
6, F - represents waterproof and non-waterproof: waterproof plus "F" for identification, not waterproof without this one
A, is the company code XM.
B, indicating that the product type is high power.
C, appearance shape (substrate) code: E, no heat sink. S, star substrate. R, round substrate. F, square substrate.
D, bracket code: bracket code.
E, wafer specification code: wafer manufacturer and wafer code.
F, illuminating color: Y yellow, R red, G green, B blue, PW is white, WW warm white.
G, power: How many W's lamp beads are written?
Lens shape: L120°, M140°, K80°, N street light, P60, Q90°, X80° funnel shape, T lensless.
As a lighting source, high-power LED has the advantages of small size, low power consumption, low heat generation, long life, fast response, safe low voltage, good weather resistance and good directionality. The cover can be made of PC tube and has a high temperature resistance of 135 degrees. , low temperature -45 degrees
1. Service life: high-power LED street lamps have a service life of more than 50,000 hours
2. Energy saving: more than 80% energy saving than high pressure sodium lamp 3. Green and environmental protection. High-power LED street lamps do not contain lead, mercury and other pollution elements, no pollution to the environment
4. Safety: impact resistance, strong shock resistance, led light in the visible range, no ultraviolet (UV) and infrared (IR) radiation. No filament and glass casing, no traditional lamp tube fragmentation, no harm to the human body, no radiation;
5. No high pressure, no dust. Eliminating the brightness reduction caused by the blackening of the lampshade caused by the high-pressure absorption of dust by ordinary street lamps;
6. No high temperature, the lampshade will not age and yellow. The utility model eliminates the brightness reduction and the shortening of the life caused by the aging of the ordinary street lamp due to the high temperature baking of the lampshade;
8. Start without delay. Led in nanoseconds, power up to normal brightness, no need to wait, eliminating the long-term start-up process of traditional LED street lights;
9. No strobe. Pure DC operation eliminates visual fatigue caused by strobe of traditional street lamps;
10. No bad glare. Eliminate the glare, visual fatigue and line-of-sight interference caused by the bad glare of ordinary high-power LED street lamps, improve the safety of driving and reduce the occurrence of traffic accidents.
11. Flexibility is good - the compactness of the LED light source enables the LED lamp to adapt to the decorative lighting requirements of various geometric sizes and different space sizes, such as: point, line, surface, ball, different forms, and even any artistic sculpture of light. ;
12. The color is pure - the color is produced by the semiconductor PN junction itself, pure, thick; rich in color - three primary colors plus digital technology, can evolve any color;
Since the invention of LED more than 30 years ago, its luminous efficiency has steadily increased, and the conversion efficiency has been achieved in two directions. Some high-brightness, high-efficiency LEDs exhibit significant photovoltaic effects, such as HP's HLMP-EG30-NR000, a red light emitter packaged in a transparent enclosure. The circuit in the figure shows how to take advantage of the photovoltaic properties of the LED. This circuit works with older red LEDs when the same components are used, but the light output is lower. The circuit of this design example describes a self-controlling LED circuit that can be determined whether it is on or off without any optical sensor assistance other than its own characteristics. When the LED is blocked, it turns on, and when it is illuminated, it turns off. The main components of the circuit include LED D1 operational amplifier IC1, monostable IC2A, and transistor switch Q1 that controls the current through the LED.
When blocked, the LED does not generate a photovoltaic current. When moderately lit (such as in an office or lab), a voltage of 50 millivolts to 100 millivolts is produced on a 4.7 MΩ load resistor. The comparator op amp IC1 compares the voltage produced by the LED to a threshold reference voltage of approximately 50 millivolts. Changing the resistance of resistors R1 and R2 connected to the voltage divider on pin 2 of IC1 can change the sensitivity threshold of the circuit.
When the ambient light is dimmed, the LED produces a lower voltage. When the voltage is below the 50 millivolt threshold, the output of the op amp goes low, triggering the monostable IC2A. Monostable turns transistor Q1 on for an interval, and the LED illuminates for about 3 milliseconds until the one-shot output goes low. In the dark room, this cycle is repeated at a rate of 200 Hz, and the LEDs are repeatedly flashed in a short cycle. At high refresh rates, the LEDs appear to be continuously illuminated.
In daylight state, the current source of the circuit mainly includes the current driving the reference bias network: 3.6V/162 kΩ=22mA. In day and night mode, the LED consumes a few milliamps of current when illuminated, and a battery of 1 amp can power the circuit for several months. Increasing the R1 and R2 values ​​also reduces the current. Since the circuit consumes low current intermittently in a well-lit environment, the life of a 1 ampere lithium battery should be close to its storage life.
